Dimensions (mm) d L P A2 A1 j K N f S E Bolt Size 85 260 219 10 36 25 19 23 186 39.7 66.3 M20 0.75in
Dimensions d A E I G L S Z B N Bolt Size 0.6875in 86mm 63.5mm 20.6mm 9.5mm 33mm 11.5mm 38.9mm 31mm 12.7mm M10mm 0.375in
Dimensions d A E I G L S Z B N Bolt Size 15mm 86mm 63.5mm 20.6mm 9.5mm 33mm 11.5mm 38.9mm 31mm 12.7mm M10mm 0.375in
Dimensions d A E I G L S Z B N Bolt Size 17mm 86mm 63.5mm 20.6mm 9.5mm 33mm 11.5mm 38.9mm 31mm 12.7mm M10mm 0.375in
Dimensions d A E I G L S Z B N Bolt Size 0.8125in 95mm 70mm 21mm 11mm 35mm 11.5mm 40.8mm 34.1mm 14.3mm M10mm 0.375in
Dimensions d A E I G L S Z B N Bolt Size 30mm 108mm 82.5mm 22.6mm 13mm 37mm 13mm 44.8mm 38.1mm 15.9mm M12mm 0.4375in
Dimensions d A E I G L S Z B N Bolt Size 0.625in 86mm 63.5mm 20.6mm 9.5mm 33mm 11.5mm 38.9mm 31mm 12.7mm M10mm 0.375in
Dimensions d A E I G L S Z B N Bolt Size 1.5625in 130mm 101.5mm 24.5mm 16mm 41mm 14mm 54.7mm 42.9mm 19mm M12mm 0.4375in
Dimensions d A E I G L S Z B N Bolt Size 45mm 137mm 105mm 24.5mm 16mm 42mm 16mm 54.7mm 42.9mm 19mm M14mm 0.5in
Dimensions d A E I G L S Z B N Bolt Size 20mm 86mm 63.5mm 20.6mm 9.5mm 33mm 11.5mm 38.9mm 31mm 12.7mm M10mm 0.375in
Dimensions d A E I G L S Z B N Bolt Size 0.75in 86mm 63.5mm 20.6mm 9.5mm 33mm 11.5mm 38.9mm 31mm 12.7mm M10mm 0.375in
Dimensions d A E I G L S Z B N Bolt Size 25mm 95mm 70mm 21mm 11mm 35mm 11.5mm 40.8mm 34.1mm 14.3mm M10mm 0.375in
Dimensions d A E I G L S Z B N Bolt Size 1.8125in 143mm 111mm 27.8mm 16mm 46mm 16mm 60.4mm 51.6mm 19mm M14mm 0.5in
Dimensions d A E I G L S Z B N Bolt Size 50mm 143mm 111mm 27.8mm 16mm 46mm 16mm 60.4mm 51.6mm 19mm M14mm 0.5in
Dimensions d A E I G L S Z B N Bolt Size 0.875in 95mm 70mm 21mm 11mm 35mm 11.5mm 40.8mm 34.1mm 14.3mm M10mm 0.375in
Dimensions d A E I G L S Z B N Bolt Size 1.0625in 108mm 82.5mm 22.6mm 13mm 37mm 13mm 44.8mm 38.1mm 15.9mm M12mm 0.4375in
Dimensions d A E I G L S Z B N Bolt Size 1in 95mm 70mm 21mm 11mm 35mm 11.5mm 40.8mm 34.1mm 14.3mm M10mm 0.375in
Dimensions d A E I G L S Z B N Bolt Size 0.9375in 95mm 70mm 21mm 11mm 35mm 11.5mm 40.8mm 34.1mm 14.3mm M10mm 0.375in
Dimensions d A E I G L S Z B N Bolt Size 1.125in 108mm 82.5mm 22.6mm 13mm 37mm 13mm 44.8mm 38.1mm 15.9mm M12mm 0.4375in
Dimensions d A E I G L S Z B N Bolt Size 1.25in 108mm 82.5mm 22.6mm 13mm 37mm 13mm 44.8mm 38.1mm 15.9mm M12mm 0.4375in
Dimensions d A E I G L S Z B N Bolt Size 1.1875in 108mm 82.5mm 22.6mm 13mm 37mm 13mm 44.8mm 38.1mm 15.9mm M12mm 0.4375in
Dimensions d A E I G L S Z B N Bolt Size 1.375in 117mm 92mm 22mm 13mm 38mm 13mm 47.4mm 42.9mm 17.5mm M12mm 0.4375in
Dimensions d A E I G L S Z B N Bolt Size 1.4375in 117mm 92mm 22mm 13mm 38mm 13mm 47.4mm 42.9mm 17.5mm M12mm 0.4375in
Dimensions d A E I G L S Z B N Bolt Size 1.25in 117mm 92mm 22mm 13mm 38mm 13mm 47.4mm 42.9mm 17.5mm M12mm 0.4375in
